Community CAD floor plans, drawn by AI

Narrow townhouse on a 5 m wide lot: 3 bedrooms, 2 courtyards

Narrow city townhouse on a 5 m wide, 22 m deep lot, single floor, side walls touching the neighbours: kitchen and dining at the street, a small open courtyard, living room, a second courtyard, then three bedrooms and a bathroom along a side corridor to the back garden

From a brief · 5 versions · 1 min of drafting · Oct 25, 2026

Guitar-shaped house, 26 m long, with music studio in the headstock

Guitar-shaped house, 26 m long: body of two joined rounded lobes (lower 13 m wide, upper 10 m) with a narrow waist. Lower lobe: living room under a round sound-hole skylight, kitchen-dining; upper lobe: two bedrooms and bathroom; neck: 3 m wide hallway ending in a square music studio

From a brief · 5 versions · 2 min of drafting · Oct 24, 2026

Honeycomb house: seven hexagonal rooms, 5 m each

Honeycomb house made of seven hexagonal rooms, each 5 m across, in a flower cluster: one hexagon in the middle, six around it. Central hexagon living room with skylight; around it kitchen, dining, two bedrooms, bathroom and entrance hall

From a brief · 5 versions · 1 min of drafting · Oct 23, 2026

Castle home 14 × 14 m with four round corner towers

Small castle home, 14 × 14 m square keep with four round corner towers (4 m diameter): towers hold a spiral staircase, bathroom, pantry and reading nook; great hall living room with fireplace in the middle, kitchen, 2 bedrooms

From a brief · 5 versions · 1 min of drafting · Oct 21, 2026

Submarine tiny home: 20 × 5 m hull with rounded ends

Submarine-shaped tiny home: one long 20 × 5 m hull with fully rounded ends. Round bow lounge with porthole windows, galley kitchen, dining nook, bathroom, captain's bunk bedroom in the round stern, a round spiral stair in the middle up to the conning tower deck

From a brief · 5 versions · 1 min of drafting · Oct 23, 2026

Flatiron-style wedge home on a triangular plot, 20 × 16 × 12 m

Triangular wedge-shaped home inspired by the Flatiron Building, on a triangular corner plot: sides 20 m, 16 m and 12 m, rounded narrow tip 2 m wide. Living room with curved window in the tip, open kitchen-dining, 2 bedrooms, bathroom, entrance hall on the long side

From a brief · 5 versions · 1 min of drafting · Oct 22, 2026

Donut house: ring home 18 m around a round courtyard

Ring-shaped donut house, 18 m outer diameter around a round 8 m open courtyard with a tree: curved rooms all along the ring: living room, kitchen-dining, 2 bedrooms, bathroom, study; glass walls facing the courtyard, one entrance passage

From a brief · 4 versions · 1 min of drafting · Oct 22, 2026

Hand sketch to CAD: ground floor with winter garden

From a photo / sketch · 5 versions · 1 min of drafting · Oct 22, 2026

Shipping container home 12.2 × 7.3 m, 2 bedrooms

Family home built from three 40 ft shipping containers side by side, 12.2 × 7.3 m: 2 bedrooms, open kitchen and living room, bathroom, laundry, a covered deck along the long side

From a brief · 5 versions · 1 min of drafting · Oct 21, 2026

Ground floor 8 × 15 m, drawn from a photo of a plan

Draw this ground floor plan as a clean CAD drawing. Walls are at least 15 cm thick.

From a photo / sketch · 5 versions · 2 min of drafting · Oct 19, 2026

Family house 12 × 10 m, 3 bedrooms

Single-storey family house, 12 x 10 m: 3 bedrooms (main bedroom with en-suite), a second bathroom, open kitchen with island and living-dining, laundry, single garage and a covered porch at the entrance.

From a brief · 6 versions · 3 min of drafting · Oct 19, 2026
